Large Volume Series Slip ring

Number of Circuits 3-137
Consult immediately
Model ListInstallationReview(0)


JINPAT's approach to solving both motion control plus power and data transmission challenges is simple – innovation and performance. JINPAT’s products consistently perform in the world’s harshest environments.

We offer leading-edge custom solutions and services that set the pace in today’s rapidly changing global markets.

For over 26 years, we have delivered trusted technology products to the maritime industries including offshore petroleum,

oceanographic, seismic and shipbuilding.


According to the specifications of the high power slip rings and the characteristics of certain industry,

JINPAT high power slip ring takes up hollow structure. This special design contributes to its easy maintenance, heat dissipation.

Meanwhile, with upper class material, the carbon brush is with high power capacity.

The capacity of a ring reaches 20000A. With low friction, JINPAT high power large current slip ring rotates in a smooth and stable way.
At present, JINPAT Electronics is developing custom electrical slip ring with higher power capacity.

Our achievements in doing R&D on high power slip ring are well recognized and represents the top standard at home and abroad.

Typical applications:   Oil drilling platform, harbor machinery, ship and crane, etc.


LPA-Large Volume Series Slip ring
Model Code

Number

   of Channels

Current(A)Voltage(V)HousingOther FeaturesApplicationDetails
LPA000-02120-01PE3

2*120A+1PE2000VACStainless Steel 316EXTIIB T5 Explosion-proof

Oil Drilling

Pipe

LPA000-02600-0440-12S18

2*600A+4*40A

+12*signal

450~750VDC
/
24V~32VDC
Q235 with spray/
Construction Machinery- Crane
LPA000-03300-01PE-0350-0210-16S25

3*300A+1PE+3*50A

+2*10A+16*signal

690VAC/380VAC

/220VAC

Q235 with spray/
Marine Cranef971691601348daa9117a3cddf614e63_ABUIABAEGAAgi5jhggYol9HW-AQwIDgg.png
LPA000-034000-01PE-0606-0203-72S-11L-01A1373*4000A+1PE+3*8A+2*3A+
54*0.25A+18*0.3A+
38*signal*
12*spare+11*PE+1*Liquid
690VAC/340VAC
/220VAC*30V/24V
Q235 with spray3MW propeller slip ring, high power, multi-channel, integrate pneumatic hydraulic channelsShip Podded Propellerf971691601348daa9117a3cddf614e63_ABUIABAEGAAgi5jhggYol9HW-AQwIDgg.png
LPA000-06405-06PE-03100-01PE-0616-02PE-0910-03PE
36

6*405A+3*100A+6*16A

+9*10A+12PE

380VACStainless Steel 304
/
Helicopter Equipment Testing Platformf971691601348daa9117a3cddf614e63_ABUIABAEGAAgi5jhggYol9HW-AQwIDgg.png
LPA000-0780-0740-0915PE-0705PE-08S-FO1250

7*80A+7*40A+16PE+

8*signal+12*FO

3200VAC/2200VAC

/24VAC

Stainless Steel

316

Umbilical Winch Slip Ring Multi-channel, High Voltage

Mining viheclef971691601348daa9117a3cddf614e63_ABUIABAEGAAgi5jhggYol9HW-AQwIDgg.png

LPA130-031000-

01PE-50S

543*1000A+1PE+50*signal

690VAC/220VAC

/24VDC

Q235with spray1MW Ship Podded Propeller Slip Ring, Through-hole DesignShip Podded Propellerf971691601348daa9117a3cddf614e63_ABUIABAEGAAgi5jhggYol9HW-AQwIDgg.png
