Pin Connection Slip Rings

Number of Circuits 2/4/6/8
Current 2A/5A/14A/ 15A/20A/25A
Insulation Resistance ≥500MΩ@500VDC
Voltage 240VAC/DC
Consult immediately
Model ListInstallationReview(0)

LPR Pin Slip Ring adopts exquisite and innovative design, and replaces wires with pins. This model complies with the RoHs standards, and is widely used in wind generators, production line equipment, rotating platform, cable reel and hot roller.


Features:

◎Pin contact instead of wire contact

◎Transmit power and signal

◎Smooth function

◎Low contact resistance

◎Easy to install


Option:

◎Rotating speed

◎Number of circuits

◎Current capacity

◎Housing material


Application:

◎Wind generators

◎Rotating platform

◎Cable reel and hot roller

◎Production line equipment


Pin Connection Slip Rings
Model

Number

of

Circuits

Voltage

(AC/DC)

Current

(A)

OD*Length

(mm)

Rotor Outer

Diameter

(D1)

Pin Base Outer

Diameter

(D2)

Rotor Pin

Length

(L1)

Rotor

Exposed

Length

(L2)

Stator Base

Length

(L3)

Stator Pin

Length

(L4)

Details
LPR-22240V2circuits* 15Aφ32*28.6Φ16Φ1689.898详情.png
LPR-33240V2circuits* 15Aφ32*28.6Φ16Φ1689.898详情.png
LPR-44240V

2circuits*5A

/2circuits*15A

LPR-66240V

6circuits*20A

LPR-88240V

6circuits*20A

/2circuits*5A






LPR Pin Slip Rings Installation Guide

1.Install the stator of the slip ring first. Mount the statorof the slip ring housing with screws. Ensure its axiality deviation is within ±0.1mm.

2.Then install the rotor side. Connect it with the drive shaft using screws or through aligning the flat positions and make sure their concentricity.

3.Adjust the concentricity of the whole slip ring unit to ensure smooth operation.

4.If wires for external connection are needed, each slip ring unit will be accompanied by a wire set upon request.





LPR Pin Slip Rings Precautions

1.Stabilize the screws with locking measures to avoid loosening and dropping due to vibrations and shocks during operation.

2.The slip ring should not bear the weight of the connected application nor radial loads.

3.Do not disassemble the inner parts of the slip ring. If any problem occurs, please consult our customer service.
